Latex paint production line

Latex paint production line

    Unit Price: 10000~100000 USD
    Min. Order: 1 Set/Sets
    Packaging: wooden case
    Productivity: 3000 kg/h
    Brand: Chile
    Transportation: Ocean,Air,Express
    Place of Origin: ChangZhou,JiangSu,China.
    Supply Ability: 50 sets per year
    Certificate: CE,ISO9001
    HS Code: 8453200000
    Port: Shanghai port

Basic Info

Model No.: CTEG3000 Latex paint production line

Product Description

3000T Latex paint Production Line
Liquid coating complete set of equipment, can choose a variety of configurations, to meet your different production
needs. Chile is a Chinese company that designs and manufactures liquid coating automation production equipment. The coating multinational company has provided complete sets of coating production equipment.You can call or write for more information.
FEATURES AT A GLANCE
1.Closed production, safety and environmental protection; 2.The filling of raw materials into finished products is fully automated 3.The equipment design is mature, the structure is reasonable, the utilization rate is high; 4.In addition to latex paint, can also achieve including true stone paint, brush paint and other varieties of product production
Production Line
PRODUCT SPECIFICATIONS
No
Item
Material
Quantity
Data
1
Electric control system
Circuit control system
1
composite member
2
Feed system
Powder adding tank
1

304 stainless steel, inside and outside mirror finish,250L
3
Feed system
Liquid filling tank
1

304 stainless steel, inside and outside mirror finish,250L
4
Feed system
Emulsion filling tank
1

304 stainless steel, inside and outside mirror finish,250L
5
Feed system
Vacuum buffer tank
1

304 stainless steel, inside and outside mirror finish,15L
6
Feed system
Additive tank
4

304 stainless steel, inside and outside mirror finish,3L
7
Feed system
Vacuum pump
1
5.5KW, pumping capacity 3M3
8
Pulping and grinding system
1000L dispersion kettle
1
304 stainless steel, upper and lower heads, inside and outside mirror polished, with seal
9
Pulping and grinding system
18.5KW disperser
1
Frequency control (0-1440), with sealing device
10
Pulping and grinding system
Grinder kettle
1
304 stainless steel, upper and lower heads, mirror polished inside and outside, with seal, with cooling jacket
11
Pulping and grinding system
New basket-type grinder
1
30KW, with seal, stepless speed regulation, speed: 0-1440 RPM
12
The paint system
Stainless steel paint mixing tank
1
2000L, upper and lower head, inside and outside mirror polished, with seal
13
The paint system
Low speed agitator
1
5.5KW, 63rpm, with sealing device
14
The paint system
Multi-function mixing tank
1
3000L, upper and lower head, inside and outside mirror polished, with seal
15
The paint system
Low speed mixer
1
7.5kW, 41rpm, anchor stirring, with sealing device
16
The paint system
High speed disperser
1
Power 22KW, frequency control (0-1440), with sealing device
17
Discharge and filtration system
Pneumatic diaphragm pump
4
DN40
18
Discharge and filtration system
Backkick bag filter
2
304 stainless steel
19
Operate stable

Operation platform,
1
Size 8.5*3.3*1.8m, stainless steel railing, 3mm aluminum alloy pattern plate
20
Filling system
Semi-automatic filling machine
1
21
Pipeline system
Pipeline fittings
1

Includes all valves, quick connections, stainless steel pipes and cables
Why Choose Us
packing for reference
shipping for reference
FAQ
Q: Can you give us a quotation right now?
A: Yes,will provide you soon.
Q: Can you give us your price list?
A: Yes,we will show you the details of price list.
Q: What is your MOQ?
A: 1 piece/set.
Q: Do you have any one in stock?
A:Sorry, we don’t. Our products are all manufactured according to customers’ requirements. So our products are all different and special.
Q: Do you accept a special order?
A: Yes, we do. We can manufacture all kinds of chemical equipment according to your technical drawings. Before you give them to us, will sign the contract and confidentiality agreement with you. You don’t need to worry about that. Or we can make a design for you according to your requirements. What we supply is not only product, but also solution and design.
Q: Can you give us the technical drawing and data?
A: We will give you the overall dimension drawing for your plan and project. But the detailed drawing and data will be sent you after we signed the contract and confidentiality agreement.
Q: Do you provide after-sales service?
A: Yes, we do. Our product is guaranteed up to one year from purchase unless man-made damage. If there is anything wrong with product itself quality problem, we will change or repair it at our charge. If not, we will provide after-sales service at your charge.
Q: Can your engineer come to our place for installation guide?
A: Yes, we can. We will provide a video and document for installation. If you still have problem, we will send our engineer oversea for installation guide.
Contact us

Pls contact us if you want to know more details.

We would like to introduce our company and products, hope that we may build business cooperation in the future.

Remark: Our main product include Mill Equipment,Mixer Equipment,Filling Equipment,Complete Production Line,Disperser Equipment,Three Roller Mill.

Chile(Shanghai) Mechanical Technology Co.,Ltd

 Chile(Shanghai) Mechanical Technology Co.,Ltd is a company focusing on the wet grinding, dispersing, emulsifying, mixing and non-standard equipment with comprehensive research, design, production, sales and service. Relying on science and technology for development, we continue to provide high-tech energy saving and environmental protection products satisfactory to the user which is our constant pursuit. On the base of the introduction of foreign advanced technology, our company has successfully developed high-speed disperser, mill, nano beads mill, high shear emulsifying machine, emulsion pump, mixer, mixing machine crusher, filtration equipmentpackaging equipment and various chemical complete sets of production line and other products. Our machines have been widely used in coatingprinting, cosmetic, medicine, daily cosmetic, food, inks, putty, mortar, resin, pigments, additives, adhesives, building materils, feed, metallurgy pesticidedetergent, washing powder, modified asphalt emulsion, paper and paper chemicals, Rubbel additives Pharmaceutical intermediatesbiological and chemical, lubricants, lithium battery slurry, wate treatment, dyeing and textile auxiliaries etc.
